Empirical Model of the Nighttime Winter Ionospheric Trough
in the Northern and Southern Hemispheres


Karpachev A.T., IZMIRAN, e-mail: karp@izmiran.ru
Klimenko V.V., West Department of IZMIRAN, e-mail: vvk_48@mail.ru
Klimenko M.V., West Department of IZMIRAN, e-mail: maksim.klimenko@mail.ru
Pustovalova L.V., IZMIRAN, e-mail: pustoval@izmiran.ru


To the Model:
Northern Hemisphere >>
Southern Hemisphere >>

BRIEF DESCRIPTION


The empirical median model of the shape and position of the MIT (Main Ionospheric Trough) in the Northern and Southern Hemispheres is presented. The model is based on the topside sounding data of the Intercosmos-19 satellite (about 2000 passes in both hemispheres) and in situ electron density Ne measurements onboard the low-orbiting CHAMP satellite (more then 20 000 passes) for high and low solar activity, accordingly.

The model is applicable to the quiet geomagnetic conditions (Kp = 2), the night-time (18:00 - 06:00 LT), the winter (November-February in the Northern Hemisphere and May-August in the Southern Hemisphere) season, and different levels of solar activity (F10.7=70-250). Model describes the dependence of trough minimum position on the local time (LT) and longitude. The resulting analytical dependence on local time and longitude for the night MIT minimum position describes its more precisely in comparison with other models.

The MIT model is practically the model of the sub-auroral ionosphere since it describes not only the trough minimum position but its shape too, i.e. the foF2 distribution in the trough region including its minimum, equatorial and polar walls of the MIT. For this purpose the Ne data obtained at CHAMP heights (400-450 km) were reduced to F2 layer peak height using the IRI model.

The MIT model input parameters are the longitude, latitude, LT and F10.7 (the ten centimeter solar radio flux http://www.ips.gov.au/Educational/2/2/5). The output parameters are the MIT minimum positions, latitudinal and longitudinal foF2 profiles and foF2 longitude-latitude maps in the trough region (from 38oN to 75oN and from 38oS to 75oS) for different LT and F10.7. The accuracy of the model is 2o in latitude, 30o in longitude, and 0.5 MHz in foF2. In the nearest future the model will be extended to the nighttime equinoctial and day time winter conditions.

ACKNOWLEDGEMENTS
The authors are grateful to sponsors and operators of the CHAMP mission: Deutsches GeoForschungsZentrum (GFZ) Potsdam, German Aerospace Center (DLR), and the US National Aeronautics and Space Administration (NASA). Some parts of this web-site and of the MIT model was developed at financial support of the Russian Foundation for Basic Research (RFBR) - Grant 14-05-00788 (Klimenko V., Klimenko M.).


REFERENCES

  • Deminov M.G., Karpachev A.T. Longitudinal effect in the main ionospheric trough configuration. I. Trough position. Geomagnetism and aeronomy, v.26, 1, p.63-68, 1986.
  • Deminov M.G., Karpachev A.T. Longitudinal effect in the main ionospheric trough configuration. 2. Trough shape. Geomagnetism and aeronomy, v.26, 4, p.682-684, 1986.
  • Afonin V.V., Deminov M.G., Karpachev A.T., Benkova N.P., Besprozvannya A.S., Shestakova L.V., Shmilauer Ya. and Schuka T.I. Longitudinal variations in the main ionospheric trough position for night winter conditions according to the Cosmos-900 and Intercosmos-19 satellites. Geomagnetism and aeronomy, v.32, 2, p.75-78, 1992.
  • Karpachev A.T. Global variations in foF2 in the nighttime trough region. Geomagnetism and aeronomy, v.32, 5, p.94-98, 1992.
  • Deminov M.G., Karpachev A.T., Afonin V.V., Shmilauer Ya. Changes of the main ionospheric trough position depending on longitude and geomagnetic activity. Geomagnetism and aeronomy, v.32, 5, p.185-188, 1992.
  • Karpachev A.T., Afonin V.V., Shmilauer Ya. Variations in the position of the night trough minimum with longitude during winter and equinox: A comparison. Geomagnetism and aeronomy, v.34, 1, p.70-75, 1994.
  • Deminov M.G., Karpachev A.T., Afonin V.V., Annakuliev S.K., Shmilauer Ya. Dynamics of mid-latitude ionospheric trough during the storm. I. Qualitative pattern. Geomagnetism and aeronomy, v.35, 1, p.73-79, 1995.
  • Deminov M.G., Karpachev A.T., Afonin V.V., Annakuliev S.K. Dynamics of mid-latitude trough during the magnetic storm: Main phase. Geomagnetism and aeronomy, 6, p.69-77, 1995.
  • Deminov M.G., Karpachev A.T., Afonin V.V., Annakuliev S.K. Dynamics of mid-latitude trough during the storms: Recovery phase. Geomagnetism and aeronomy, v.36. 4. p.45-52, 1996.
  • Deminov M.G., Karpachev A.T., Annakuliev S.K., Afonin V.V. and Smilauer Ya. Dynamics of the ionization troughs in the night-time subauroral F-region during the geomagnetic storms. Adv. Space Res., v.17, 10, p.141-145, 1996.
  • Karpachev A.T., Deminov M.G., Afonin V.V. Model of the mid-latitude ionospheric trough on the base of Cosmos-900 and Intercosmos-19 satellites data. Adv. Space Res., v.18, 6, p.221-230, 1996.
  • Annakuliev S.K., Afonin V.V. Deminov M.G., Karpachev A.T. Empirical formula for the position of the main ionospheric trough during magnetic storms. Geomagnetism and aeronomy, v.37, 3, p.183-187, 1997.
  • Karpachev A.T., Afonin V.V. Dependence of the ionospheric trough occurrence probability on the season, local time, longitude, and level of magnetic activity Geomagnetism and aeronomy, v.38, 3, p.79-91, 1998.
  • Karpachev A.T., Deminov M.G. and Afonin V.V. Two branches of day-time winter ionospheric trough according to Cosmos-900 data at F2-layer heights. Adv. Space Res., v.22, 6, p.877-882, 1998.
  • Karpachev A.T., Afonin V.V. Variations in the position of daytime ionospheric winter troughs with longitude. Geomagnetism and aeronomy, v.39, 2, p.65-71, 1999.
  • Karpachev A.T. Characteristics of a Ring Ionospheric Trough. Geomagnetism and aeronomy, v.41, 1, p.57-66, 2001.
  • Karpachev A.T. Dependence of the trough shape on longitude, altitude, season, local time, solar and magnetic activity. Geomagnetism and aeronomy, v.43, 2. p.256-269, 2003.
